The application of Joysticks in the field of shipping
The Joysticks control stick, also known as the yacht control stick driving system, has extensive and significant applications on yachts.
I. Achieve precise and flexible control
1. Low-speed 360-degree rotation: Yachts like the Azimut Atlantis 45 are equipped with JOYSTICK joysticks, which, in combination with the bow side push, can control the vessel to rotate 360-degree at low speeds. In narrow waters or ports, the captain can easily turn the yacht on the spot and find the right Angle to dock, greatly enhancing the yacht's maneuverability in complex environments.
2. Multi-directional movement and compound operation: The outboard motor control lever driving system launched by Mercury Marine for single-engine floating vessels enables the owner to freely move the control lever and activate multiple commands, such as simultaneous rotation and lateral movement, allowing the yacht to move horizontally or diagonally in any direction, achieving actions that are difficult to perform with traditional driving methods and enhancing the flexibility and accuracy of operation.
---------------------------------------------------
II. reduce the difficulty of driving operations
1. Simplify mooring operations: For inexperienced drivers or users encountering twin-engine ships for the first time, mooring can be a challenging task. The Fairline Squadron58 flybridge yacht is equipped with an optional joystick control system, making mooring much easier. The joystick integrates multiple complex control actions. By simply pushing the joystick forward, backward, left and right, one can perform operations such as moving the yacht forward, backward, turning and sideways, lowering the operational threshold and intensity for the driver. This enables the driver to complete the berthing of the yacht without mastering complex operational skills.
2. Reduce driving fatigue: During long voyages or frequent berthing and unberthing operations, traditional driving methods require drivers to frequently operate multiple control devices, which can easily lead to fatigue. The integrated operation mode of the JOYSTICKS joystick enables drivers to control the yacht more easily, reducing the complexity and physical exertion of operation, and enhancing the comfort and safety of driving.
---------------------------------------------------
III. Work in coordination with other systems
1. In coordination with the propulsion system: The JOYSTICK control stick equipped on the Azimut Atlantis 45 yacht works in coordination with Volvo Penta's latest third-generation IPS propulsion system. It can precisely adjust the engine's power output and propulsion direction according to the instructions of the control stick, achieving efficient, stable navigation and flexible control.
2. Complementary to navigation and monitoring systems: The flybridge steering console of the Horizon V77 CMY yacht is equipped with advanced electronic devices (such as three 22-inch Garmin MFDS and Maretron digital monitoring systems) and ZF joysticks. The JOYSTICKS joystick driving system works in tandem with these devices. While the driver acquires information such as location and sea conditions through the navigation system, they can precisely control the yacht's movement using the joystick. The monitoring system can also provide real-time feedback on the yacht's status to ensure navigation safety.
---------------------------------------------------
IV. Applicable to various types of yachts
1. Power boat Powerboats with excellent sports performance such as the Azimut Atlantis 45 and the Beneteau Gran Turismo 36 designed for family cruises and entertainment both apply the JOYSTICKS joystick. Meet the demands of different powerboats in terms of handling and driving experience.
2. Pontoon Boats: Mercury Marine has launched an outboard motor control lever driving system for single-engine pontoon boats, making it easier for pontoon boat owners to operate during mooring and in confined Spaces, filling the previous gap in control lever functions for single-engine pontoon boats.
